Chapter 1: Introduction
1-5
X9SPU-F Motherboard Headers/Connectors
Connector/Switch Description
UID-LED Unit ID Switch
SBX2 Slot for Supemicro riser card P/N RSC-R1UW-E8R
SBX1, SBX3, UIO-RISER Slots for Supermicro riser card
T-SGPIO1~T-SGPIO2 Serial Link General Purpose I/O Headers (5V Gen1/Gen 2)
I-SATA0, I-SATA1 SATA 3.0 Connectors via PCH (6Gb/s)
I-SATA2~I-SATA5 SATA 2.0 Connectors via PCH (3Gb/s)
KB/MS PS/2 Keyboard and Mouse Ports
FAN1~FAN5 System/CPU Fan Headers
SPEAKER Internal Speaker (Leave jumper on JSPK installed, pins 1-2)
JSD1 SATA Disk On Module (DOM) Power Connector
JSTBY1 Legacy Wake On LAN Header
JPW1 24-pin Main ATX Power Connector
JPW2 8-pin Secondary Power Connector for the GPU
JPI2C2 Power Supply SMBus I2C Header
JF1 Front Panel Control Header
JL1 Chassis Intrusion Header
JLED 3-pin Power LED Header
JSPK Internal Speaker/Buzzer Select or External Speaker Header
USB4/5 Rear USB Ports
JUSB4, JUSB3 Internal USB 3.0 Headers USB0/1, USB2/3
USB12/13 Internal USB 2.0 Headers USB12/13
BAT Onboard Battery
JTPM Trusted Platform Module (TPM) Header
LAN1/LAN2 Rear LAN Connectors (1Gb)
COM1, COM2 Rear Serial Port (COM1), Serial Port Header (COM2)
VGA Rear VGA Port
DIMMA1~DIMMB2 DIMM Memory Slots
IPMI Rear IPMI LAN Port
