Chapter 1: Introduction
1-7
Motherboard Features
CPU Single Intel® Xeon E3-1200 v2 processor family and Gen-2
Core-i3 (LGA 1155) processors. It is also backward compat-
ible with Xeon E3-1200 processors.
Memory Four (4) UDIMM slots support up to 32GB of DDR3 Unbuf-
fered, ECC or non-ECC UDIMM memory, 1333/1600MHz..
Supports dual-channel memory bus
DIMM sizes
UDIMM 1GB, 2GB, 4GB, 8GB
Chipset Intel® C216 Express
Expansion PCI Slots (Supported on Supermicro Riser Cards)
One (1) PCI-Express 3.0 x16 slot
One (1) PCI-Express 2.0 x4 in x8 slot
One (1) PCI-Express 2.0 x4 in proprietary slot
One (1) Universal I/O (UIO) Slot
Network Connections Integrated LAN
Two (2) Intel 82574L Gb LAN ports
I/O Devices SATA Connections
SATA 3.0 Ports Two (2) 6 Gb/s
SATA 2.0 Ports Four (4) 3 Gb/s
RAID 0, 1, 5, 10
USB Devices
Two (2) USB 2.0 ports on the rear I/O panel
Two (2) USB 2.0 via one header for front panel access
Four (4) USB 3.0 via two headers for front panel access
Serial (COM) Ports
Two (2) Fast UART 16550 connections on the I/O
backpanel and one header
Super I/O
Winbond Super I/O NCT6776F
BIOS 32 Mb SPI AMI BIOS
®
SM Flash BIOS
Plug & Play, DMI 2.3, ACPI 1.0 (Limited), USB Keyboard
support
Power Conguration ACPI/ACPM Power Management
Main Switch Override Mechanism
Power-on mode for AC power recovery
