1-8
X9SPU-F Motherboard User’s Manual
PC Health Monitoring CPU & Chassis Monitoring
Onboard voltage monitors for CPU core, +3.3V, +5V, +/-
12V, +3.3V Stdby, +5V Stdby, VBAT, HT, Memory, Chipset
CPU 4-phase switching voltage regulator
CPU/System overheat LED and thermal control
CPU Thermal Trip support
CPU & Chassis Environment Monitor
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width
Modulation) fan speed control
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 2.0
support
System resource alert via SuperDoctor III
SuperoDoctor III, Watch Dog, NMI
Chassis Intrusion header and detection
CD Utilities BIOS ash upgrade utility
Drivers and software for Intel® C216 chipset utilities
Other ROHS 6/6 (Full Compliance, Lead Free)
TPM 1.2 on board
DOM (Disk on Module) Power Connector Support
FCC B, EuP Lot 6, WHQL
Dimensions 8" x 13" UIO form factor, 6 layers
