Chapter 6 Function & Setting (P400)
www.supmea.com
seconds to enter the filling function (the calibration
transmitter is full, which will involve the accuracy and
performance. Do not operate in the case of no standard
source).
(3) In setting mode, add one function for setting
parameters, and long time continuous shift plus one.
(1) Press shortly in the measurement mode to modify the
display mode.
(2) Press and hold for 5 seconds in the measurement
mode to enter the zero function (to calibrate the
transmitter zero point).
(3) In the setting mode, for setting parameter
displacement and reduce function, to shift or subtract one
continuously in a long time.
6.3 Monitoring menu
There are two types of access codes, depending on the size of
the transmitter.
(1) 4~20mA output: the entry password is "00001", and the
display unit, display resolution and display mode can be set.
(2) RS485/RS485&4~20mA output: the entry password is
"00016", which can be set as shown in table 1.
Function setting (4~20mA output)
Loc: password input menu, range can be set (19999 ~ 99999),
