Function Description/Action
Get Faults
Touch [GET FAULTS] to show the number of active faults and the fault number currently
being displayed.
Arrows The Left and Right arrows at the top of the page scroll through messages.
Diagnostic
Message and
Description
Field
Most common SPNs and FMIs have text for the description stored in the display. If there is
no text, then this SPN and FMI must be defined by referring to the engine manufacturer or
the SAE J1939 standard.
Source Indicates the source of the message.
SPN
Suspect Parameter Number - fault code
If not translated into text by the display, see the engine manufacturer's literature for the
definition of the SPN number.
FMI
Failure Mode Indicator - fault code
The FMI is defined by SAE J1939. If not translated into text, see the SAE standard or the
engine manufacturer's literature.
Count Number of messages.
ENG Hours Number of in-use engine hours.
Corrective
Action
Suggested action for correction.
