Product specifications
18
Product specifications
Category Feature Specification
Credential
Biometric
Fingerprint
RF Option
•
BEW2-OHP: 125kHz HID Prox
• BEW2-ODP: 125kHz EM & 13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa,
NFC
• BEW2-OAP: 125kHz EM, HID Prox & 13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1,
FeliCa, iCLASS SE/SR, NFC
RF read range
*
MIFARE/DESFire/EM/HID Prox/iCLASS : 50 mm, FeliCa: 30 mm
General
CPU
1.2 GHz Quad Core
Memory
2GB Flash + 256 MB RAM
LED
Multi-color
Sound
Multi-tone Buzzer
Operating temperature
-20°C - 50°C
Storage temperature
-40°C - 70°C
Operating humidity
0% - 80%, non-condensing
Storage humidity
0% - 90%, non-condensing
Dimension (W x H x D)
50 mm x 172 mm x 43.5 mm (Bottom) / 38.2 mm (Top)
Weight
Device: 251g
Bracket: 43g (Including washer and bolt)
IP rating
IP67
IK rating
IK09
Certificates
CE, FCC, KC, RoHS, REACH, WEEE
Fingerprint
Image dimension
272 x 320 pixels
Image bit depth
8bit, 256 grayscale
Resolution
500 dpi
Template
SUPREMA / ISO 19794-2 / ANSI 378
Extractor / Matcher
MINEX certified and compliant
LFD
Supported
Capacity
Max. User (1:1)
500,000
Max. User (1:N)
100,000
Max. Template (1:1)
1,000,000 (Two templates per finger)
Max. Template (1:N)
200,000 (Two templates per finger)
Max. Text Log
1,000,000
Interface
Ethernet
Supported (10/100 Mbps, auto MDI/MDI-X)
RS-485
1ch Master / Slave (Selectable)
Wiegand
1ch Input / Output (Selectable)
TTL input
2ch Input
Relay
1 Relay
PoE
Supported (Power over Ethernet 44 VDC Max 12 W, IEEE 802.3af )
Tamper
Supported
Electrical
Power
Voltage: DC 12 V, Current: Max. 600 mA
* Use 12VDC, 1.5A power supply.
Switch input VIH
Min. 3 V
Max. 5 V
Switch input VIL
Max. 1 V
Switch Pull-up resistance 4.7 kΩ (The input ports are pulled up with 4.7 kΩ.)
Wiegand output V
OH
More than 4.8 V
Wiegand output V
OL
Less than 0.2 V
Wiegand output Pull-up
resistance
Internally pulled up with 1 kΩ
Relay
Voltage: Max. 30VDC
Current: 1A
* RF read range will vary depending on the installation environment.
* Access control feature (UL294 specification)
Destructive attack - level2, Line security - level2, Endurance - level1, Standby power- level1
