Controls, Features and Options
8-5
• NEUTRAL - The lever is detented in the NEUTRAL position (center of travel) for
starting; the neutral safety switch allows starting in this position only. For engine
warm-up, a separate lever or button on the control is used to allow the throttle to
advance only while the transmission remains in NEUTRAL.
• FORWARD - Release the detent lock to allow shifting to the FORWARD
position. Moving the lever into the first 15° of travel (toward the bow or up)
positions the control in the FORWARD detent IDLE position. Advancing the
lever beyond 15° allows throttle increase in FORWARD.
• REVERSE - Release the detent lock to allow shifting to the REVERSE position.
Moving the lever into the first 15° of travel (toward the stern or down) positions
the control in the REVERSE detent idle position. Advancing the lever beyond
15° allows throttle increase in REVERSE.
Figure 5
Figure 8-5
Figure 6Typical Shift and Throttle Control
Figure 8-6
KC-0197-A
FORWARD SHIFT
RANGE
REVERSE SHIFT RANGE
IDLE
IDLE
SAFETY
COLLAR
NEUTRAL
FORWARD
THROTTLE
RANGE
REVERSE
THROTTLE
RANGE
FULL
THROTTLE
NEUTRAL
LOCKOUT
FULL
THROTTLE
