Ÿ Over current protection
Ÿ Short Circuit and Over Temperature Protection
Ÿ Click & Pop Noise Reduction
Note: If the fault condition persists, the protection circuit stays in shutdown until the
fault is removed.
1.4 Applications
Ÿ AV receivers
Ÿ Powered speakers
Ÿ Sub-woofers
Ÿ Musical Instrument amplifiers
Ÿ PA System
Ÿ External Car Speaker System
Ÿ Background Music Systems
Ÿ Home DIY
Ÿ Prototype for recording studios, post-production, live sound and hi-fi applications.
1.5 Benefits
Ÿ Mounting holes facilitate installation and fixing
Ÿ Excellent heat dissipation eliminates the requirement of an extra heat sink.
1.6 Quick Start
Suggested connection is shown in figure 1-3.
FIGURE 1-3 CONNECTION SCHEMATIC
Note: Please observe the following steps to complete verification so as to ensure the
products are intact during transit.
