2.2 Input Connections
You may use RCA connectors to input audio signal.
FIGURE 2-2 INPUT CONNECTION
TABLE 2-2 INPUT CONNECTION
Connector Mark Channel Description
RCA connector
RCA1A
Channel 1 Input
RCA1B
Channel 2 Input
2.3 Output Connections
You can use terminal blocks SPKR1A、SPKR1B to output audio signal.
FIGURE 2-3 OUTPUT CONNECTION
