Sure Electronics JAB4 - Analog Line Input

Audio Input
4
4, Analog Line Input – J13
JAB4 supports analog input and J13 is used for
3.5mm AUX IN.
The terminal block used is PH-6pos-2mm.
You can find the 3.5mm AUX IN cable in the
Functional Cables Kit (AA-JA11117).
J13
Pin definition of
3.5mm AUX IN cable
NC
NC
