Power Supply
Suggested power supply should be DC24V, 3A.
You can also use any power supply whose output voltage is
within DC10-26V and current is higher than 3A. Please note
power supply out of the recommended range may cause
damage to the amplifier board.
We recommend MeanWell LRS-100-24 Single Output Switching
Power Supply. We also recommend Mean Well GST-90A 24V
version.
The terminal interface used for power supply is Molex
MicroFit-2Pos-3mm.
A power supply cable is the basic cable, which comes with
JAB4 in the package.
1, Power supply – J6
1
J6
