LED Indicator
5, Bluetooth LED indicator – J1
When Bluetooth is paired, the LED will be ON;
When Bluetooth is searching, the LED will BLINK.
LED1, Bluetooth LED indicator
LED2, Signal detection LED indicator
Signal level sensor system is employed in JAB4 for lower
power consumption.
When there is signal detected, the LED will be ON;
When there is no signal detected, the LED will be OFF.
5
J1
LED1,
Bluetooth
Indicator
LED2,
Signal Detection
Indicator
On-board LED indicator
