Audio Output
11, I2S output – J9
Besides speaker output, JAB4 provides I2S
output, which can be transmitted into
another I2S amplifier board.
In this condition, JAB4 is set as master
mode as default.
The terminal block used for I2S output is
PH-6Pos-2mm.
