Control
11. Control Synchronization Port – J10
JAB5 supports cascading with another JAB5
to get 8 x 100W or other audio systems.
This control synchronization port is provided
to make sure the control logic of two
connected boards are consistent, so that the
built audio systems eliminate “POP” noise
and offer simple control.
Please do not use J10 when JAB5 is used
separately.
You can find the PH-3Pos cable in the
Function cables kit.
10
10
Slave
Mode
Master
Mode
J10
J10
