Control
J11 port is provided for easy control of the
audio systems.
Short circuit J11, JAB5 will enter into standby
mode.
Leave J11 open, JAB5 will work normally.
You can find the PH-2Pos cable in the
Functional cables kit.
Note: Take definition for J1 and J12 from data
sheet.
12. Standby Control – J11
11
J11
