18
Kitting Information
Kitting Information
Component Product Number / Description Gain / Loss
LTE-A LTE-V Cellular
800 MHz
PCS
1900 MHz
AWS
1700 / 2100 MHz
Outdoor Antenna SC-288W: Omni 3 dBi 3 dBi 3 dBi 4 dBi 4 / 4 dBi
SC-230W: Yagi 10 dBi 10 dBi 10 dBi 10 dBi 10 / 10 dBi
Outdoor Cable SC-240-40 ft FN, Use 40 ft or longer 3.52 dB 3.52 dB 3.98 dB 6.52 dB 6.12 / 6.92 dB
SC-400-75 ft, NN, Use 75 ft or longer 4.22 dB 4.22 dB 4.41 dB 6.17 dB 5.8 / 6.54 dB
Indoor Cable SC-240-20 ft, FN, Use 20 ft or longer 2.06 dB 2.06 dB 2.29 dB 3.56 dB 3.36 / 3.76 dB
SC-400-30 ft, NN, Use 30 ft or longer 2.05 dB 2.05 dB 2.12 dB 2.83 dB 2.68 / 2.98 dB
Indoor Antenna SC-222W: Dome 3 dBi 3 dBi 3 dBi 6 dBi 6 / 6 dBi
SC-248W 7 dBi 7 dBi 7 dBi 10 dBi 10 dBi / 10 dBi
The Force5S Canada booster is suitable for use with all equivalent and lower gain antennas, as well as, equivalent or greater
lengths of cable.
Frequency (MHz) Bandwidth (MHz) Input (dBm) Mean Power (dBm) Gain (dB)
Uplink: 1710-1755 72.0 -56.4 22.1 78.5
Uplink: 1850-1915 70.0 -46.4 21.0 67.4
Uplink: 824-849 34.2 -46.0 21.2 67.2
Uplink: 698-716 26.7 -45.5 23.8 69.3
Uplink: 777-787 23.6 -47.1 21.7 68.8
Downlink: 2110-2155 78.5 -56.8* 20.0 76.8
Downlink: 1930-1995 73.5 -50.9 17.3 68.2
Downlink: 869-894 36.8 -50.8 17.3 68.1
Downlink: 728-746 34.3 -49.1 19.8 68.9
Downlink: 746-756 35.3 -46.0 20.5 66.5
*Input power level is decreased before reaching AGC-0.5 dB to maintain compliance with the intermodulation product of -13 dBm.
Mean power: Measurements obtained on section 6.2 where Pmean = P01+3 dB
