SurgeX Defender Series - 6 Specifications

User Manual
© 2013 SurgeX / Electronic Systems Protection, Inc. / Technical Support 800.645.9721 / www.surgex.com / 25
3. Specifications
Parameter
Specification
Load Rating
SX-HS-15-R
15 Amps at 120 Volts
SX-HS-20-R
20 Amps at 120 Volts
SX-HS-L530-R
30 Amps at 120 Volts
SX-HS-L630-R
30 Amps at 120/230 Volts Split Phase
SX-HS-L630-RDB
2 x 30 Amps at 120/230 Volts Split Phase
Voltage Protection Rating
(VPR)
SX-HS-15-R
SX-HS-20-R
330V All Modes
SX-HS-L530-R
Pending
SX-HS-L630-R
SX-HS-L630-RDB
800V Line-Line
500V Line-Ground
Attenuation
Normal
Mode
SX-HS-15-R
SX-HS-20-R
SX-HS-L530-R
SX-HS-L630-R
SX-HS-L630-RDB
> 30 dB 80kHz – 50MHz
Common
Mode
SX-HS-15-R
SX-HS-20-R
SX-HS-L530-R
> 30 dB 70kHz – 50MHz
SX-HS-L630-R
SX-HS-L630-RDB
> 30 dB 200 kHz – 50MHz
Power Requirement
(no load)
SX-HS-15-R
SX-HS-20-R
4 Watts
SX-HS-L530-R
SX-HS-L630-R
SX-HS-L630-RDB
6 Watts
Under-Voltage Shutdown
120V Models
Adjustable from 80V to 95 V, or Disabled. Restores at 105V.
208/230V Models
Adjustable from 140V to 170 V, or Disabled. Restores at 190V.
Over-Voltage Shutdown
120V Models
Adjustable from 135V to 160V. Restores at 130V.
208/230V Models
Adjustable from 260V to 300V. Restores at 250V.
Internal Memory Capacity
60 Events with timestamp; 999 counts of each event type
Timestamp Accuracy
± 2.5%
Voltmeter Accuracy
(Peak Reading Type)
120V Models
± 2% Typical product accuracy between 40V and 180V
208/230V Models
± 2% Typical product accuracy between 100V and 300V
Response Time
Over-Voltage
100 msec
Under-Voltage
150 msec
Under-Voltage Record
Definition
120V Models
AC Voltage has dropped below 100V
208/230V Models
AC Voltage has dropped below 180V
Over-Voltage Record
Definition
120V Models
AC Voltage has risen above 135V
208/230V Models
AC Voltage has risen above 260V
Power Outage Event Definition
AC Voltage has dropped below 20V
Surge Event Definition
Surge + Diagnostic has been exposed to a transient voltage in one of the 3 possible
modes (between Live and Neutral, between Live and Ground, between Neutral and
Ground) with a peak amplitude of 500V-700V* or higher and a frequency of 20 kHz or
higher. *500V-700V surge voltage amplitude applies to IEEE C62.41 Category B
Impulse; surge voltage amplitudes necessary for detection of other surge types may
vary.
