1. SURGE + DIAGNOSTIC PRODUCT OVERVIEW
The Surge + Diagnostic is a state-of-the-art, microprocessor-controlled, power protector and conditioner with real-
time data acquisition and storage.
Models: This manual applies to the following Surge + Diagnostic models:
Key Features:
Normal and Common Mode EMI Noise Filter
Multi-Stage Normal and Common Mode AC Surge Protection
Zero-Voltage Turn-On
Zero- Current Turn-Off
Inrush Current Elimination (ICE
®
)
Wiring Fault Detection
Catastrophic Over/Under Voltage Shutdown (CouVS
®
) with selectable thresholds
Under-Voltage Event Recorder (up to 999 events)
Over-Voltage Event Recorder (up to 999 events)
Power Outage Event Recorder (up to 999 events)
Surge Event Recorder (up to 999 events)
o Records surges in all three modes: Line-Neutral, Line-Ground, Neutral-Ground (120V)
o Records surges in all three modes: Line1-Line 2, Line1-Ground, Line2-Ground (120/230V)
Event Timestamp Recorder (up to 60 events)
o Records time between events
LCD Event Monitor cycles through:
o Under-Voltage Events
o Over-Voltage Events
o Power Outage Events
o Surge Events
o Last Recorded Event Type
o Output Status (On or Off)
o Additional information in certain circumstances
(detailed in Section 3.1: Hardware/ LCD Event Monitor)
Additional features available when connected to a PC
(detailed in Section 4: Diagnostic Software)
Technical Support:
To download software and access further product information, visit www.surgex.com
For technical support, please contact SurgeX at 1-800-645-9721
