EXHAUST SYSTEM 7-3
• Disconnect the No. 2 cable 3 and then No. 1 cable 4 from
the pulley.
• Remove the EXCVA 5.
• Remove the EXCV cover 6 from the EXCV pulley.
• Disconnect the No. 1 7 and No. 2 8 cables.
EXCVA INSPECTION
!5-83
EXCV INSPECTION
• Turn the EXCV by hand and check that it moves smoothly.
• If it does not move smoothly, replace the EXCV together with
the muffler body.
• Decarbonize the EXCV if necessary.
#
CABLE INSPECTION
• Inspect the cables for wear or bend if it is damaged, replace it
with a new one.
NOTE:
The EXCV cables are identified by the plated chrome color and
shape.
No. 1 cable 1: 11276-48G0
No. 2 cable 2: 11277-48G0
* Do not attempt to disassemble the EXCV.
* The EXCV is available only as the muffler body
assembly.

Suzuki VZR1800N 2008 Specifications

General

Manufacturer	Suzuki
Model	VZR1800N
Year	2008
Displacement	1783 cc
Bore x Stroke	112.0 x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Lubrication	Wet sump
Cooling system	Liquid cooled
Transmission	5-speed
Final Drive	Shaft Drive
Rear Brakes	Single disc
Category	Cruiser
Engine Type	V-twin
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual disc
Front Tire	130/70R18M/C 63H
Overall Length	2485 mm
Ground Clearance	140 mm
Fuel Capacity	19 L
