2-16 PERIODIC MAINTENANCE
SPARK PLUG INSTALLATION
• Screw the spark plugs into the cylinder head with fingers, and
then tighten them to the specified torque.
# Spark plug: 11 N·m (1.1 kgf-m, 8.0 Ib-ft)
"
IGNITION COIL/PLUG CAP INSTALLATION
• Install the ignition coils/plug caps and connect their lead wire
couplers.
"
FUEL LINE
• Inspect the fuel feed hose 1 for damage and fuel leakage. If
any defects are found, the fuel feed hose must be replaced.
EVAPORATIVE EMISSION CONTROL
SYSTEM (E-33 ONLY)
Inspect the evaporative emission control system periodically.
Do not cross thread or over tighten the spark plug, or
such an operation will damage the aluminum threads
of the cylinder head.
* Do not hit the ignition coil/plug cap with a plastic
hammer when installing it.
* Place the ignition coil/spark plug cap so that the cou-
pler does not touch the cylinder head cover.
CONTACT
INCORRECT
INCORRECT
Inspect every 6 000 km (4 000 miles, 12 months).
Inspect every 12 000 km (7 500 miles, 24 months).

Suzuki VZR1800N 2008 Specifications

General

Manufacturer	Suzuki
Model	VZR1800N
Year	2008
Displacement	1783 cc
Bore x Stroke	112.0 x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Lubrication	Wet sump
Cooling system	Liquid cooled
Transmission	5-speed
Final Drive	Shaft Drive
Rear Brakes	Single disc
Category	Cruiser
Engine Type	V-twin
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual disc
Front Tire	130/70R18M/C 63H
Overall Length	2485 mm
Ground Clearance	140 mm
Fuel Capacity	19 L
