swaploader SL-160 - Cylinder, Tank, Pump & Controls Parts

Section V: Parts
5.0.PAR.SL-160
90H89 – BASE CYLINDER CIRCUIT SL-160
ITEM
PART
#
QTY DESCRIPTION
WT-
lb/ea.
WT-
lb/all
1
90H74 1 Nylon Hose Sleeve x 60" 0.25 0.25
2
10P39 2 Adp Hyd 08MJ/08MB 0.30 0.60
3
10P43
2
Adp Hyd 08MJ/08MJ BHD
0.30
0.60
4
11P23
6
Adp Hyd 08MJ/08MB 90
0.30
1.80
5 12P51 1 Hose Assy 42 08-08FJ/08FJ45 2.05 2.05
6
12P52
1
Hose Assy 38 08-08FJ/08FJ45
1.90
1.90
7
12P53
1
Hose Assy 21 08-08FJ/08FJ45
1.26
1.26
8
12P54
1
Hose Assy 17 08-08FJ/08FJ45
1.11
1.11
9
12P55
1
Hose Assy 31 06-08FJ/08FJ45
1.43
1.43
10
12P58 2 Adp Hyd 08MJ/08MJ/08MJ Tee 0.30 0.60
11
12P85 4 Adp Hyd 08FJ/08MJ 45 0.30 0.60
12
13P14
4
Adp Hyd 08FJ Cap (-8)
0.30
0.60
13
13P72
1
Hose Assy 78 08-08FJ/08FJ
4.68
4.68
14
13P74
1
Hose Assy 109 08-08FJ/08FJ45
5.45
5.45
15
21P28
1
Hyd Valve, 2-Way 16 GPM
2.20
2.20
5-8
