Section III: Operation
3.0.OPE.SL-212
OPERATING INSTRUCTIONS
LOADING A CONTAINER
STEP 1. Engage the P.T.O. (refer to P.T.O. manual for operation).
STEP 2. Retract the jib (right control lever backward). Then, tilt the arm backward (left control lever
backward).
STEP 3. Make sure the work area in front of the container is clear of people and obstacles. Move the truck
backwards until the hook engages the curved lifting bar of the container. NEVER EXTEND THE
JIB to reach the proper catching height, rather tilt the arm.
WARNING:
MAKE SURE WORK AREA IS CLEAR OF PEOPLE AND OBSTACLES PRIOR
TO DUMPING OR UNLOADING CONTAINERS. SWAPLOADER STRONGLY
RECOMMENDS THAT A BACKUP ALARM BE INSTALLED ON THE TRUCK
CHASSIS. THE OPERATION OF THE HOOK HOIST IS THAT THE TRUCK IS
BACKED UP TO THE BODY TO PICK IT UP AND SO THERE IS A POTENTIAL
PINCH POINT BETWEEN THE BODY AND THE HOOK.
