Product description
Front
1. PowerLED: Thislightindicatesthattherouterreceivespower.
2. SYSLED:  AconstantlyblinkingSYSlightindicatescorrectfunctioningoftherouter.
3. WPSLED: Whenthislightblinks,itispossibletoconnecttotherouterwithaWPSenableddevice.Formoreinformation,see
thechapter:“Securingyourwirelessnetwork”.
4. WLANLED: Thislightindicatesthatthewirelessnetworkisactive.Aflickeringlightindicateswirelessactivity.
5. LANPort1-4LED: ThislightindicatesanactiveconnectiononthecorrespondingLANport.Aflickeringlightindicatesnetworkactivity.
6. WANPortLED: ThislightindicatesanactiveconnectionontheWANport.AflickeringlightindicatesWANactivity.
Back
1. ACpowerinput: Connectthesuppliedpoweradaptertothisinput.Iftheadapterislostitcanbereplacedbyasimilarmodelwith9V
ACoutputand1.2Acurrentrating
2. WANport: ConnectthenetworkcablecomingfromyourISPmodemtothisport.UponasuccessfulWANconnection,theWAN
lightatthefrontoftherouterwilllightup.Thisisaprerequisiteforinternetaccess.
3. LANport1-4: Youcanconnectanetworkcablecomingfromacomputertothisport.Whenthecomputeristurnedonthe
correspondinglightatthefrontoftherouterwilllightup.
4. WPSbutton: ThisbuttonactivatesWPSwirelesssecurity.FormoreinformationonWPS,seethechapter“Securingyourwireless
network”.Thisbuttonalsofunctionsastheresetbutton,formoreinformationontheresetprocedurerefertothe
troubleshootingsectionofthismanual.
Installing the router
There are three ways of installing the router:
• TheInstallationWizardprogramincludedontheCD
• TheSimplesetupdescribedinthismanual
• TheAdvancedsetupalsodescribedinthismanual.
Thewizardandsimplesetupassumedefaultsettingsandwillworkformostusers.Ifyouareanadvanceduserorifyouknowwhichsetupmethod
yourISPrequires,youmayproceedtotheadvancedsetupimmediately.
