1. Supply air filter, F7 + heat resistant filter
2. Extract air filter, G3
3. Heat exchanger
4. Service switch
1. Extract air fan
2. Supply air fan
3. Condensate discharge connection
4. The fan’s locking device
5. Partition wall
1
2
3
4
1
2
3
4
4
The ventilation unit’s fans must be loosened from their
locations and protected, for example, with plastic bags, while
the ventilation ducts are cleaned.
The figures show the R-model of the ventilation unit.
5
The damper motor can be released if necessary by moving
the release magnet on top of the motor directly opposite
the “magnetic gear release” mark. When the magnet is in
position, the summer bypass damper can be opened or closed
manually.
