TOWING CODE
19
AK160 Type Hitch head
Fig. A
Open the locking mechanism by pulling the
coupling handle upward in the direction of the
arrow (Fig.A item 1). The handle will remain
in the open position until the hitch head is
positioned onto the towball.
Release the caravan handbrake and
manoeuvre the hitch head over the greased
towball and re-apply the handbrake. Using
the jockey wheel winding handle, lower the
hitch head carefully onto the towball. The
pressure of the towball within the hitch head
will release the locking tongue with an audible
click and the coupling handle should drop
down. For safety check that the coupling
handle is fully down by pushing the handle
down manually. When the hitch head is
correctly coupled to the tow ball the green
collar of the locking display button will be
visible. (Fig A item 2). If the green collar is
not visible it is not safe to tow the caravan.
Contact your dealer for advice.
