3.5 12 Volt DC Fuses
! WARNING: When replacing fuses always
replace a fuse with the correct value. NEVER
replace with a higher value /
rating as this could damage the wiring
harness. If a replacement fuse ‘blows’
do not keep replacing the fuse as you
could damage the wiring harness. Please
investigate the fault and contact your dealer.
Note: Fuses (2-13) have a Red LED below
them which provides indication that the fuse
has blown. The charger fuse has a green
LED which Indicates that the charger is
working.
The following table shows details of the fuse(s)
located at the Leisure battery. See also 3.4A
SWIFT COMMAND POWER CONTROL SYSTEM
Fuse Rating Fuse Colour Description
1 25 Amps White Charger
2 7.5 Amps Brown Permanent 12V / Alarm / Fridge Electronics / Alde Heating
3 10 Amps Red 12V Sockets / TV Amplifier / Radio
4 10 Amps Red Extractor Fans / Truma Heating / Whale Space Heater
5 5 Amps Tan Appliances / Hob Ignition / Toilet / Whale Water Heater
6 10 Amps Red Water Pumps
7 7.5 Amps Brown Lighting, Main Lights & Dim Channel 1.
8 5 Amps Tan Lighting, Entry Light & Dim Channel 2.
9 10 Amps Red Spare Outputs / Marker Light
10 10 Amps Red Auxiliary / Awning Light
Fuse Rating Fuse
Colour
Description
Battery 1 20
Amps
Yellow Fuse remotely located near battery
Battery 2 20
Amps
Yellow Fuse remotely located near battery 2 (where fitted)
