SERVICES
40
5) Adjust dust cover over opening in water
container as shown in image below. Please
note dust cover should not be secured to
water container, as air must be allowed to
enter the container to replace the water be-
ing pumped out..
Slide lid up to unlock and remove plug. When
removing the plug, simply pull the plug clear of
the socket using the hand grip.
Please note: It is recommended that you
change your Whale water filter every 3000
litres or after approximately 30 days of use as
smells and debris will build up in the filter and
effect the pump’s performance. No other main-
tenance is required.
WARNING: This filter cartridge should not
be used in water supplies of an unknown
bacteriological quality. This is not a bacterial
filter.
Plumbing Connections
In most cases, speed fittings are used,
which allow easy and quick connection of
water pipes.
To connect a pipe to a fitting, simply push the
pipe into the connector. To remove the pipe,
push the collar of the fitting inwards, and then
withdraw the pipe.
To connect a pipe, simply push the pipe into
the connector.
To remove a pipe, push the collar inwards, and
then remove the pipe.
As a note, when refitting the pipe, ensure
the end of the pipe is round (not oval) and
the cut is square. If not, it could lead to
water leaks.
PLUMBING CONNECTIONS
Plug connector to inlet, with
hose in water container, and
dust cover in place
