3.17 System Warnings
The system incorporates a number of warnings that are active at specific times. These are
summarised below, and also covered by relevant sections of this manual. When a warning is active a
triangle will be displayed in the control panel header area.
Warning When Type
Fresh water level
low
With pump turned on and fresh
water level low (less than 25%
full). Only available when an on-
board tank is fitted.
Message on screen and 30 second
audible beep.
Leisure battery
voltage low
With control panel power on and
leisure battery selected (as active
battery) and the voltage level falls
below 10V
Message on screen and 30 second
audible beep.
Message on screen and 30 second
audible beep. If no action taken after
30 seconds then the system will
switch the power off to prevent severe
discharge of the battery
With control panel power on and
leisure battery selected (as active
battery) and the voltage level is
below 9V
Note: This is an emergency cut off level to protect the battery from severe
damage. You should not rely on this cut off level during normal operation,
but manage your power consumption to a discharge level of 11.5V or
above.
This cut off only applies to power drawn from the battery by the leisure
equipment that is controlled by the control panel power switch; it will not
protect the battery from discharge by permanently connected equipment.
Leisure battery
voltage high
With control panel power on or
off and leisure battery is selected
(as active battery) and the
voltage level rises above 15V.
Message on screen and repeated
beeps from the control panel. The
power is automatically turned off. The
beeping will not stop until the fault is
cleared.
Vehicle battery
warnings
If the vehicle battery is selected instead of the leisure battery, with the
towing vehicle connected, then similar warnings to those described above
are applied to the vehicle battery. The vehicle battery low warning level is
10.9V
Engine running When the engine is started the
system power will be turned off.
Message on screen, Leisure & Vehicle
battery symbols indicating both
batteries are connected for charging.
The charging voltage is also shown on
screen.
Mains lead
(hook-up cable)
still connected /
plugged in
When the engine is started and
the mains cable is still plugged in
and the charger is switched on.
Message on screen and repeated
beeps from the control panel. The
beeping will not stop until the hook-up
lead is removed.
