Services
29
4. Note the position of actuator before re-
moval. Flange should be facing forward.
5. Remove actuator.
6. To remove shroud, squeeze clips with one
hand and slide shroud off with other hand.
7. Remove microswitch, using finger and
thumb, pull up and outwards.
8. Slide wire terminals off microswitch.
9. Attach replacement microswitch and
relocate. Note: Ensure microswitch snaps
fully home.
10.Before relocating shroud ensure wires are
neatly located in the front groove as
shown.
11.Replace shroud.
Note: Ensure shroud
locating rib is aligned with the rear groove
of tap and snap fully home, ensuring clips
are retaining the shroud.
12.Replace actuator in position noted in 4
above.
13.Replace lever and fix with screw.
Note: Do not overtighten screw.
14.Replace lever cap.
WINTERISING
To avoid damage as a result of freezing, drain
the entire water system. To protect Elite tap
or shower units, the tap control(s) and the
shower control should be opened when
draining the system to enable stored water in
the outlets to drain back through the control
valves and out of the system. (Switch off
pump at isolator). Ensure that both the hot
and cold systems are fully drained by
draining separately. The cold drain plug is a
separate drain plug from the heater drain
plug. The lever should be up and in the
centre to drain the hot and cold system when
not in use. Remove water filter if fitted.
Please consult your dealer if in difficulty.
If they are unable to solve the problem,
contact Whale Customer Services:
tel: 01247 270531 ext. 211 or 213.
GUIDANCE ON CLEANING PORTABLE
WATER TANKS AND THE WATER SYSTEM
IN TOURING AND MOTOR CARAVANS
The water systems, and in particular storage
tanks, in caravans are susceptible to
contamination by bacteria if care is not taken
with their use and cleaning. The symptoms
caused by bacterial contamination are not
purely limited to gastro-intestinal diseases,
but may also manifest themselves as ear,
nose, throat, eye or skin infections. It is
therefore important that you carry out the
following procedure prior to using the
caravan each time, even if you boil or filter all
water you use for drinking.
Separate Water Containers
1. All water remaining in the container
should be disposed of so that the
container is empty.
2. The outside of the container should be
thoroughly cleansed and washed down to
remove any dirt, dust or other contaminant.
Water at a suitably hot temperature
containing an appropriate detergent is
recommended for this purpose.
3. Water should be put in the container,
swirled around, then emptied out.
4. The container should then be totally filled
with water containing an appropriate
sterilant solution and allowed to stand for
the recommended contact time (e.g.
Milton for 15 minutes).
5. The solution should be emptied from the
container.
6. The opening of the container should be
cleaned thoroughly with an appropriate
prepared wipe impregnated with a
sterilant.
7. The container should be inverted whilst
stored overnight (if possible).
8. The container must be filled with mains
water only and mains water only should
be used for the above cleaning
procedure.
9. On no account should garden hoses be
used to fill water tanks.
