DISTRIBUTION PANEL
Indicator Module
Battery / Water Level Meter
This meter indicates the amount of fresh
water remaining in the inboard water tank.
Simply press the test switch to the water
position and the meter will display a level on
the following scale:
Empty -
1
/
4
-
1
/
2
-
3
/
4
- Full
To test battery voltage simply press the test
switch to the battery position, readings
should be taken as shown below.
Battery Condition Meter
This battery condition meter indicates the
power remaining in your caravan battery.
Readings should be taken as follows:
Green region - Fully charged
(no charge necessary)
Yellow region - Adequate charge
(re-charge if desired)
Red region - Low charge
(turn on charger switch
to re-charge)
Also included in this module is a pump
running indicator. This red indicator will light
up as a warning when the water pump has
been activated.
Switch Module
This module contains all the control switches
for electrical facilities within the caravan.
12V Isolation Switch
This switch will effectively isolate 12 volt
power to all dc circuits by opening a relay.
This switch should be used only when
wishing to isolate power for reasonably short
periods (e.g. when going out for the day).
For isolation during storage the Car/Van
switch on the ESM2000 unit should be used
(place Car/Van switch to the centre 'off'
position)
Pump switch
This switch merely energises the inboard
water pump ready for use. In caravans with
an outboard pump, this switch will be a two
way type for energising whichever pump is
required (i.e. internal or external)
Entry Light switch
This switch energises an internal entry light.
Battery / Water test switch
This switch should be pressed to the battery
position to test battery voltage or the water
position to test the water remaining in the
inboard tank.
DISTRIBUTION PANEL
for specific models
Switch & Indicator Module
Water Level Meter
This meter indicates the amount of fresh
water remaining in the inboard water tank.
Simply press the test switch to the water
position and the meter will display a level on
the following scale:
Empty -
1
/
4
-
1
/
2
-
3
/
4
- Full
Battery Condition Meter
This battery condition meter indicates the
power remaining in your caravan battery. To
test battery voltage simply press the test
switch to the battery position, readings
should then be taken as follows:
Green region - Fully charged
(no charge necessary)
Yellow region - Adequate charge
(re-charge if desired)
Red region - Low charge
(turn on charger switch
to re-charge)
Pump switch
This switch merely energises the inboard
water pump ready for use. In caravans with
an outboard pump, this switch will be a two
way type for energising whichever pump is
required (i.e. internal or external). The RED
