Fitted Equipment
69
8. Adjust the temperature in the main
refrigerator compartment using rotary
switch (B)
For models with automatic ignition
1. Set the energy selector switch (A)
to gas
2. Press and hold rotary thermostat switch (B)
3. The ignition process is activated
automatically, accompanied by a ticking
sound; the indicator lamp (D) will flash.
Upon successful ignition, the sound and
flashing will stop.
4. Keep rotary switch (B) depressed for
another 10-15 seconds, then release.
5. If there is an inspection glass, check to
see that the flame is burning.
6. If the flame goes out the ignition system
will repeat the ignition process
automatically.
8. Adjust the temperature in the main
refrigerator compartment using rotary
switch (B)
Note:
The fridge must exclusively be operated
using liquid gas (propane and butane)
All refrigerators are equipped with
automatic flame protection, which
automatically cuts off the gas supply 30
seconds after the flame goes out.
When using for the first time or after
changing the gas cylinder, the gas pipes
may contain air. By means of brief
operation of the refrigerator and any other
gas appliance (eg cooker) air is removed
from the gas pipes. The gas will then
ignite without delay.
Main 230V Operation
Note:
The operation may only be selected
where the supply voltage of the
connection for the power supply
corresponds to the value specific on the
data plate. Any difference in values may
result in damage to the appliance.
1. Set the energy selector switch (A) to
2. Use rotary switch (B) to regulate the
temperature in the main refrigerator
compartment.
12V/24V Operation
Only operate your refrigerator on 12V/24V
when the engine of your vehicle is running.
Install through a relay otherwise your battery
will soon be discharged.
Note:
Before operating the refrigerator on
12V/24V, it should be pre-cooled, together
with its contents, by running it on gas or
230V for a few hours before changing
over to 12V/24V for your journey.
1. Set the energy selector switch (A) to
The refrigerator will run continuously without
thermostatic control.
FRIDGE USE AND MAINTENANCE
WINTER OPERATION
Please check that the ventilation grilles or
the flue outlet are not blocked by snow,
leaves etc.
Some caravans with outside ventilation may
have so called winter covers that protect the
cooling unit against cold air (ask your
dealer). The covers may be fitted when the
outside temperature is below approx. 10°C
and should be fitted when the temperature is
below freezing point.
We suggest that you fit the winter covers
when the vehicle is laid up during winter
months.
FOOD STORAGE
Always keep food in closed containers.
Never put hot food in the refrigerator; allow it
to cool first.
Never keep items in the refrigerator
which might give off flammable gases.
The frozen food compartment is intended for
the storage of frozen food and for making
ice. It is not suitable for freezing items of
food.
