Fitted Equipment
CASSETTE C-200 CW AND C-200 CWE
The toilet section of the C-200 includes a
rotatable bowl, removable seat and cover, a
console with a flush handle/flush buttons, a
built in flush-watertank and a waste level
warning indicator. Underneath the bowl, the
valve blade handle is located.
PREPARING FOR USE
1. Open access door pull retaining clip
upwards (fig. 1).
2. Remove holding tank by pulling straight
out. When holding tank hits the stop, tilt
front end downwards slightly and remove
(fig. 2).
3. Position tank vertically and swivel pour-
out spout upwards (fig. 3).
4. Remove the cap of the pour-out spout.
Add required quantity of toilet fluid
through pour-out spout then add approx.
2 litres of water through the spout to
cover holding tank bottom. Replace cap
and return pour-out spout to its original
stored position (fig. 4).
Note: Warmer weather or longer
intervals between emptying the waste
tank may require additional toilet fluid.
Use only Thetford toilet fluid to achieve
the best results.
Caution: Never add toilet fluid directly
into toilet bowl.
5. Slide the holding tank into position
through access door (fig. 5).
6. Make sure the holding tank is secured by
the retaining clip. (fig. 6).
7. Open the waterfill door and add 50 ml of
Aqua Rinse. Aqua Rinse results in a
better flush and improves the hygiene of
the toilet. Then fill the watertank with
fresh water using a jerrycan or a hose.
Tank capacity is 7 litres (fig. 7).
OPERATION
8. Turn the bowl in the most comfortable
position (fig. 8)
9.
C-200 CW only: Before using the toilet it
is recommended to flush some water
into the bowl by lifting and pressing down
the flush handle (fig. 9).
9a.
C-200 CWE only: Before using the toilet
it is recommended to flush some water
into the bowl by pressing and releasing
the flush button (fig. 9a).
89
THETFORD CASSETTE
C-200 CW (Manual)
and C-200 CWE (Electric)
FEATURES
1. Removable seat and cover.
2. Rotatable bowl.
3. Valve blade handle: opens and closes
valve blade.
4. Flush-handle activates the flush by lifting
and pushing down the handle.
4a C-200 CWE. Flush button: activates
flush.
4b
C-200 CWE. Valve blade buttons: open
and close valve blade electronically.
5. Power-supply for the waste-level
indicator: two batteries, type: Penlite 1,5V
AA alkaline.
6. Waste-level indicator: indicates when
holding tank requires emptying.
7. Rotating pour-out spout: makes emptying
holding tank easy and convenient.
8. Upper carrying handle
9. Automatic holding tank vent: vents the
holding tank when the tank is inserted in
the toilet. This prevents under- or
overpressure in the holding tank.
10. Valve blade opener.
11. Sliding cover: closes automatically when
holding tank is taken out. Guarantees
optimal hygiene.
12. Valve-blade
13. Vent button: vents the holding tank to
avoid splashing while emptying.
14. Hand grip
15. Access door
16. Waterfill door
87
