Fitted Equipment
HEATING AND WARM WATER WITH BOTH
230 V HEATING CARTRIDGE AND LPG
BOILER
(Use only when electricity or gas alone is not
sufficient)
1. Open the LPG shut-off valve.
2. Switch the circulation pump switch to
position (I).
3. Switch the LPG switch to position (F).
4. Switch the heating cartridge switch to the
desired output position (B, C or D).
In the illustration, an output of 2100 W
has been selected.
5. Adjust the temperature to the desired
level (5-30°C) using the TPS control
thermostat (K).
SETTINGS FOR OPERATION OF THE
HEATING SYSTEM AND WARM WATER
HEATER
For more information on the settings on the
panel, please refer to the 'Control Panel'
section.
SWITCHING OFF THE LPG BOILER,
HEATING CARTRIDGE AND CIRCULATION
PUMP
1. Switch all three switches on the control
panel to the O-position (H, E, A).
2. Close the main switch to the heating
system if the vehicle will not be used.
If the main switch is not closed, the boiler
will remain in the stand-by position and
use a small amount of electricity.
3. Close the LPG shut-off valve.
IF THE RED LED-LIGHT COMES ON
The boiler is fitted with an ionised flame
sensor. This means that if the flame goes out
for some reason, the electronics will attempt
to re-light it. If the flame is not re-lit within
ten seconds, the solenoid valve switches off
the gas supply, the electronics are blocked
and the red LED (G) on the control panel is
switched on. The electronics must be reset
before the boiler can be started.
Resetting from the blocked position:
1. Switch the LPG switch to position (E).
The LED (G) will go out.
2. Wait approx. 30 seconds while the
electronics reset the block.
3. Switch the LPG switch to position (F).
The electronics will once again attempt to
start the boiler.
TP5 ELECTRONIC
PROGRAMMABLE ROOM
THERMOSTAT
FEATURES
- Controls central heating systems to
provide different room temperatures up to
6 times a day
- The TP5 has one programme for Monday
to Friday, with a different programme for
Saturday and Sunday.
- Setting the TP5 to the lowest temperature
will effectively switch off the heating,
whilst providing frost protection for the
controlled area*
RESET
The unit may be reset to 12:00PM (MO) and
the factory set programme by pressing and
holding down the four buttons, temperature
▲ and ▼ , time + and - , until the display
goes blank.
SETTING THE CLOCK
Press the PROGRAMME button once; the
colon is no longer flashing. Use the + and -
button to set the time. Hold down a button to
change the time quickly; press and release a
button to change the time by one minute.
When the time and AM or PM are correct,
press the PROGRAMME button to start the
clock, now only the day and the colon are on
display. Use + or - button to select the
63
