ELECTRICS
81
Dimensions
EC468, EC469 PSU Overall size (HxWxD)
315 x 195 x 150mm
Clearances 75mm above,
50mm left & right
Weight 2.9 Kg
EC462, EC467 Control Panel Overall size (HxWxD)
87 x 250 x 15mm
Cut-out size (HxW)
70 x 233mm
Fixing centres 130*75mm
Weight 114 g
4.3 Approvals
System: BSEN 1648-1, BSEN1648-2
compliant, BS7671: 2008 compliant
Residual Current Device: RCD 40A 30mA trip
to BS EN 61008
Miniature Circuit Breakers: MCB’s type C
6000A breaking capacity to BSEN 60898
Electro Magnetic Compatibility (EMC) directive
2004/108/EC Certificate CE20071224-1
Integrated Charger: BS EN 60335-1/2.29,
2006/95EC, IEC61000-3.2/3:1995, 1.
Low Voltage Directive: 2006/95EC TUV-
014900-A1, EN55022, Class B, EN55024/
Level 2
12V Operation of Electrical Items
Most appliances within your product are
designed to function when supplied with a
12V feed, either from a leisure battery or the
on-board charger.
However, customers should note that some
items may have limited functionality when the
battery is in a lower voltage state (i.e. circa
10V). The Swift Group makes every effort
when specifying components to operate at low
voltages, but is not responsible if a component
fails to work at lower voltages.
Components that are typically affected by low
battery voltage include, but are not limited to,
the pump, the radio and some lights which
require higher voltages for start-up.
