ELECTRICS
80
4.Technical Data & Approvals
4.2 Motorhome Equipment -
EC460,465,468,469,470 PSU & EC461,462,466,467 Control Panel
Outline Specification
INPUT 230v 230 Volts / 0 to 16 Amps + / - 10%
OUTPUT 230v RCD protected, 3 x MCB
outputs of 10A
Separate switched channels
for water heater, space heater
and charger
EC470 2 x 10A MCB Outputs
& 1 x 16A MCB Output
(Alde systems only)
INPUT 12v 2 x 20A battery inputs via
2 x 4 way connectors
SOLAR INPUT 1 x Dedicated solar panel
input (20 to 100W panel) via a
2 way connector
OUTPUT 12v 25A total output via multiple
switched channels protected
by 14 fused outputs
CHARGER Input 220-240 Volts AC +/-
10%, Frequency 50 Hz +/-
6%, Current 3A max.
DC Output 13.6 to 14.4 Volts
nominal, Current 25 Amps
max (300 Watts).
Overall size (HxWxD)
50 x 250 x 135mm
Fixing centres 128*128mm
1.2kg
Signal INPUT 4 x Fresh water level, 4 x
Waste water level, 1 x Engine
running, plus multiple vehicle
connections
Fresh water negative sensed
Waste water negative sensed
Data IN / OUT CANBUS Data communica-
tion and power to Control
Panel via 6 way connector
IP rating IP31
Operating temperature Ambient 0 to 35°C
PSU case temperature with
full load 65°C Max
Automatic shutdown and
restart if overheated / over-
loaded
ELECTRICAL DATA
