Swift SW150 User Manual

I. Specifications
Model
SW150
Observation tube
Monocular, 360° rotatable
Inclination
30°
Eyepiece
Wide-field 10X and 25X
Nosepiece
Triple revolving
Objectives
4X, 10X, and 40X Achromatic
Magnifications
40X, 100X, 250X, 400X, and 1000X
Stage
Plain stage with slide clips
Stage size
90mmx90mm
Condenser
Single lens condenser with 6-hole disc diaphragm
Focusing
Coaxial coarse and fine focus knobs
Illumination
Dimmable top and bottom LED lights
Power
100-240V AC adapter or 3 AA batteries (included)
2

Swift SW150 Specifications

General

Observation tube	Monocular, 360° rotatable
Eyepiece	Wide-field 10X and 25X
Nosepiece	Triple revolving
Objectives	4X, 10X, and 40X Achromatic
Magnifications	40X, 100X, 250X, 400X, and 1000X
Condenser	Single lens condenser with 6-hole disc diaphragm
Focusing	Coaxial coarse and fine focus knobs
Illumination	Dimmable top and bottom LED lights
Inclination	30°
Stage	Plain stage with slide clips
Stage size	90mmx90mm
Power	100-240V AC adapter or 3 AA batteries (included)
