Swift SW380 Series User Manual

3
I. Specifications
Model
SW380B
SW380T
Head
360° rotatable Binocular
Siedentopf
360° rotatable Trinocular
Siedentopf
Inclination
30°
Eyepieces
Wide-field 10X and 25X pairs
Interpupillary
distance
48-75mm
Diopter adjustment
On left tube, +/-5dp
Nosepiece
Quadruple revolving
Objectives
Achromatic
4X, NA 0.1, working distance 37.5mm
10X, NA 0.25, working distance 6.54mm
40X(Spring), NA 0.65, working distance 0.63mm
100X (Spring, Oil), NA 1.25, working distance 0.195mm
Magnifications
40X, 100X, 250X, 400X, 1000X and 2500X
Stage
Double-layered mechanical stage with slide holder
Stage size
130mmx130mm
Stage X-Y range
70mmx30mm
Upper limit stop
Rack stop preset but adjustable
Condenser
NA 1.25 with iris diaphragm, swing-in and swing-out filter holder
Focusing
Coaxial coarse and ultra-fine focusing system
Fine focus precision
3.4µm increments
Illumination
Built-in 1W LED transmitted illumination with intensity control
Power
110-240V, built-in transformer
