SWIT S-1093F - Optional Battery Plate

17
Optional Battery Plate
1. Battery Mount choice
S-1093F monitor can use V-mount, Gold mount and various DV batteries by connecting with SWIT
S-7004 series battery plates. There’re following types of S-7004 for choice:
Model Compatible battery type Recommended SWIT battery
S
-
7004F
SONY L series NP
-
F770/970
S
-
8972, S
-
8970, S
-
8770
S
-
7004U
SONY BP
-
U series U60/30
S
-
8U63
, S
-
8U93
S
-
7004D
Panasonic
D54/D28
&
VW
-
VBD58
S
-
8D62
,
S
-
8D58
S
-
7004B
Panasonic VW
-
VBG6
S
-
8BG6
S
-
7004J
JVC BN
-
V4
28U
S
-
8428
S
-
7004V
JVC BN
-
VF823
S
-
8823
S
-
7004I
JVC SSL
-
JVC50
S
-
8I50
S
-
7004C
Canon BP series BP
-
930/945/970G
S
-
8945, S
-
8845
S
-
7004E
Canon DSLR, LP
-
E6
S
-
8PE6
S
-
7004S
SONY V
-
mount batteries
S
-
8080S, S
-
8110S, S
-
8160S.etc
S
-
7004A
Anton Bauer Gold mount ba
tteries
S
-
8080A, S
-
8110A, S
-
8160A.etc
2. Installation of S-7004F/D/J/C/U/E/B/V/I snap-on type DV battery plate:
S-7004F/D/J/C/U/E/B/V/I DV plate is snap-on type, quick release and interchangeable. Please
follow the instructions to install:
(1) Please make sure the power terminals are clean and in well condition before use.
(2) Align the S-7004 DV plates slots to the bolts of the monitor rear panel, and press tightly in.
(3) Fix the S-7004 DV plates by provided screws on the top side.
(4) Mount the corresponding battery to S-7004 DV plate to power the monitor.
(5) To release the battery, press the battery release button to take out the battery
