SY Electronics OMEGA 3 User Manual

sy.uk 10 V1.0
Specifications
General
HDMI Version
Input: HDMI 2.0 - HDR (10, 12) and HBR supported
Max Bandwidth
HDMI Input: 18 Gbps (4K60 4:4:4)
HDBT input: 10.2 Gbps (4K60 4:2:0, 4K30 4:4:4)
HDMI output: 18 Gbps (4K60 4:4:4)
HDCP Compliance
Input HDCP: 1.4 and 2.2
Output HDCP: Fully controlled – Pass, 1.4, 2.2, Cascade mode
RS232 (Control Commands – Tx, Rx)
57600 baud, 8 data bits, 1 stop bit, no parity
RS232 (Pass-Through – Tx, Rx)
Any baud rate to maximum of 115200.
Video and Audio
Video Formats
Supported
All VESA resolutions to 4096x2160p, and all 3D formats – Examples:
4096x2160p 24/25/30/50/60Hz
3840x2160p 24/25/30/50/60Hz
2560x1440 50/60Hz
2048x1152 50/60Hz
1920x1080p 24/25/30/50/60Hz
1920x1080i 50/60Hz
1280x720p 50/60Hz
All PC resolution including 1920x1200 – Examples:
1920x1200 60Hz
1680x1050 60Hz
1600x1200 60Hz
1440x900 60Hz
1400x1050 60Hz
1366x768 60Hz
1360x768 60Hz
1280x1024 60Hz
1280x960 60Hz
1280x800 60Hz
1024x768 60Hz
Colour space
RGB, YCbCr 4:4:4, 4:2:2, 4:2:0
Colour depth
8, 10, 12 bits
Output video Formats
Supports all video formats as per input or as set by the Scaler.
Audio Format Supported
2.0 / 5.1 / 7.1 channel LPCM, Dolby, AC3, DTS
Power Supply
Power Consumption
9W max.
Supply Voltage
48V/0.5A (supply voltage range 24-48V)
Environmental and Physical
Operating Temperature Range
0 to +40°C (+32 to +104 °F)
Operating Humidity Range
10 to 90 % RH (non-condensing)
