Owner's Manual
© 2006, Sycamore SCS, LLC.
13
Assembly
Wheel and Handle Assembly
Confirm that the following sub-assembly components are included:
• 1 Wheel Axle
• 2 Heavy Duty Wheels
• 4 Large Washers
• 2 Cotter Pins
• 1 Front Stand-off Support V-Leg
• 2 Support V-Leg Mounting Screws
• 1 Handle
• 1 Handle Mounting Bracket
• 1 Back Plate (Mounting Bracket)
• 3 Hinge Bolt Mounting Nuts
• 3 Three Inch Mounting Bolts
Wheel Assembly
Perform the following tasks to install the heavy duty wheels onto the generator assembly:
1. Insert axle through brackets located on the bottom cross bar of the frame.
2. Center axle in frame and place each wheel over each end of the axle, then insert axle end into the
hole located in the center of the wheel hub.
3. Place each large washer over the axle ends and insert axle through center of washer until washer
is flush against wheel hub.
4. Insert straight side of cotter pin into one of the holes located at both ends of the axle rod and
thread the cotter pin through the hole until pin snaps into place.
5. Repeat using the second cotter pin on the opposite end of the axle to secure the opposite wheel
to the axle assembly.
V-Leg Support Assembly
Perform the following tasks to install the V-leg support bracket:
1. Align V-leg support mounting holes with the mounting holes on the bottom of the frame.
2. Insert one mounting bolt completely through each mounting hole.
3. Twist mounting screws to catch the threads in the frame mounting holes and weld nuts and tighten
until support leg is secure.
