6000 Watt Generator
© 2006, Sycamore SCS, LLC.
14
Assembly (cont'd)
Handle Assembly
Perform the following tasks to install the handle onto the generator frame:
1. On the side of frame with mounting holes, place back plate in the middle of handle bracket and
frame. Handle bracket should have handle mounting holes facing downward.
2. Align frame, back plate and handle bracket mounting holes.
3. Insert one mounting bolt through handle bracket, back plate, frame, and into mounting nut.
Twist mounting nut lightly.
4. Insert the second mounting bolt through the second mounting hole. Twist mounting nut until nut,
frame, back plate, and handle bracket surfaces are flush.
5. Return to first nut and tighten.
6. Align handle mounting holes with mounting holes on handle bracket.
7. Insert mounting bolt completely through handle and bracket.
8. Install a mounting nut onto bolt and tighten. Make sure handle can swivel.
To Next Page
