Sycamore 6000L - Engine Parts Listing - Figure F

Owner's Manual
Engine Parts Listing (cont’d)
Figure F
ITEM
NO.
DESCRIPTION PSYCG # QTY
ITEM
NO.
DESCRIPTION PSYCG # QTY
F01 CLAMP PSYCG7000EF01 1
F09 COVERNOR SHAFT CLIP PSYCG7000EF09 1
F02 PAN HEAD SCREW M5 X35 PSYCG7000EF02 1
F10 COVERNOR SHAFT PSYCG7000EF10 1
F03 SPRING PSYCG7000EF03 1
F11 FLANGED NUT M6 PSYCG7000EA11 1
F04 REGULATING SPRING PSYCG7000EF04 1
F12 BACK SPRING PSYCG7000EF12 1
F05 LINK ROD PSYCG7000EF05 1
F13 AIR FLOW COVER PSYCG7000EF13 1
F06 GOVERNOR ARM PSYCG7000EF06 1
F14 FLANGED BOLT M6 x 12 PSYCG7000EF14 3
F07 SQUARE HEAD BOLT M6 PSYCG7000EF07 1
F15 OIL SEAL GOVERNOR SHAFT PSYCG7000EF15 1
F08 WASHER Ø8.2 Xø16 PSYCG7000EF08 1
© 2006, Sycamore SCS, LLC.
23
