Sycamore 6000L - General Parts Listing - Figure A (contd)

Owner's Manual
© 2006, Sycamore SCS, LLC.
17
General Parts Listing (cont’d)
Figure A (cont’d)
ITEM
NO.
DESCRIPTION PSYCG # QTY.
ITEM
NO.
DESCRIPTION PSYCG # QTY.
A01 ENGINE PSYCG6000LA01 1
A34 FRAME PSYCG6000LA34 1
A02 FLANGE PSYCG6000LA02 1
A35 RIGHT COVER PSYCG6000LA35 1
A03 SOCKET HEAD BOLT M10x25 PSYCG7000EA03 4
A36 SOCKET BOLT M8x55 PSYCG7000EA36 1
A04 HEX NUT M8 PSYCG7000EA04 4
A37 HANDLE PSYCG7000EA37 1
A05 SPRING WASHER Ø8.2xØ16 PSYCG7000EA05 4
A38 ACORN NUT M8 PSYCG7000EA38 3
A06 SOCKET HEAD BOLT M8x30 PSYCG7000EA06 4
A39 HANDLE BRACKET PSYCG6000LA39 1
A07 HEX BOLT M8x248 PSYCG6000LA07 1
A40 HEX SOCKET BOLT M8x50 PSYCG6000LA40 2
A08 BOWL WASHER Ø9 x Ø17.5 PSYCG7000EA08 1
A41 BACK PLATE PSYCG6000LA41 1
A09 SPRING WASHER Ø8.2 x Ø13 PSYCG7000EA16 1
A42 FLATE WASHER Ø8.2 x Ø13 PSYCG7000EA42 2
A10 ALTERNATOR PSYCG6000LA10 1
A43 TOP COVER PSYCG6000LA43 2
A11 FLANGED NUT M6 PSYCG7000EA11 3
A44 NUT FLANGED M6 PSYCG7000EA11 4
A12 FLANGED BOLT M6x12 PSYCG7000EA12 3
A45 BUSHING PSYCG7000EA45 4
A13 MUFFLER PSYCG6000LA13 1
A46 RUBBER GASKET PSYCG7000EA46 4
A14 DOUBLE SIDED M8x25 SCREW PSYCG7000EA14 2
A47 WASHER Ø6.6xØ22 PSYCG7000EA47 4
A15 HEX HUT M8x13 PSYCG7000EA15 2
A48 FLANGED BOLT M6x20 PSYCG7000EA48 4
A16 FLAT WASHER Ø8.2 x Ø813 PSYCG7000EA42 8
A49 FUEL TANK PSYCG7000EA49 1
A17 MUFFLER GASKET PSYCG7000EA17 2
A50 FILTER NET PSYCG7000EA50 1
A18 MUFFLER CONNECT PIPE PSYCG7000EA18 1
A51 FUEL TANK CAP GASKET PSYCG7000EA51 1
A19 RUBBER PAD PSYCG7000EA19 2
A52 FUEL TANK CAP PSYCG7000EA52 1
A20 FLANGED BOLT M8x14 PSYCG7000EA20 2
A53 FUEL GAUGE PSYCG7000EA53 1
A21 BOTTOM FOOT PSYCG6000LA21 1
A54 FUEL COCK PSYCG7000EA54 1
A22 FLANGED NUT M8 PSYCG7000EA22 2
A55 BACK COVER PSYCG6000LA55 1
A23 FRONT COVER PSYCG6000LA23 1
A56 LEFT COVER PSYCG6000LA56 1
A24 FLANGED BOLT M5x8 PSYCG7000EA24 24
A57 WHEEL PSYCG6000LA57 2
A25 HANDLE GRIP PSYCG7000EA71 1
A58 WASHER Ø16xØ30 PSYCG6000LA58 4
A26 MUFFLER INSULATION BOARD PSYCG7000EA69 1
A59 SPLIT PIN Ø3x25 PSYCG6000LA59 2
A27 HEX BOLT M10x40 PSYCG7000EA67 2
A60 AXLE PSYCG6000LA60 1
A28 ACORN NUT M610 PSYCG7000EA68 2
A61 FUEL TUBE PSYCG6000LA61 1
A29 ISOLATOR(RUBBER MOUNT) PSYCG7000EA29 4
A62 CLAMP PSYCG7000EA62 2
A30 HEX BOLT M10x25 PSYCG7000EA30 4
A63 SMALL FLANGED BOLT M6x8 PSYCG7000EA03 6
A31 WASHER Ø10.2 x Ø20 PSYCG7000EA31 12
A64 MUFFLER COVER PSYCG7000EA66 1
A32 SPRING WASHER Ø10.2 x Ø16 PSYCG7000EA32 8
A65 FLAT SCREW M6x10 PSYCG7000EA72 2
A33 HEX NUT M10 PSYCG7000EA03 8
