Sycamore 6000L - Installation Overview

6000 Watt Generator
© 2006, Sycamore SCS, LLC.
26
Engine Parts Listing (cont’d)
Figure H (cont’d)
ITEM
NO.
DESCRIPTION PSYCG #
QT
Y.
ITEM
NO.
DESCRIPTION PSYCG # QTY
H01K PULL START ASSEMBLY (H01-04) PSYCG7000EH01K
1
H25 RING SEAL PSYCG7000EH25
2
H01 FLANGED BOLT M6 x 18 PSYCG7000EH01 3
H26 CRANKCASE COVER PSYCG7000EH26
1
H02 RECOIL STARTER PSYCG7000EH02 1
H27 OIL SEAL Ø52 x Ø35 x 8 PSYCG7000EH27
1
H03 HEX NUT M16 x 1.5 PSYCG7000EH03 1
H28 FLANGED BOLT M8 x 40 PSYCG7000EH28
7
H04 STARTER PULLEY PSYCG7000EH04 1
H29 CYLINDER HEAD GASKET PSYCG7000EH29
1
H05 FAN COVER PSYCG7000EH05 1
H30 INSIDE SHEILD PSYCG7000EH30
1
H06 FLANGED BOLT M6 x 12 PSYCG7000EH06 4
H31 CYLINDER HEAD COVER PSYCG7000EH31
1
H07 FLYWHEEL FAN PSYCG7000EH07 1
H32 GAS PIPE PSYCG7000EH32
1
H08 FLYWHEEL PSYCG6000EH08 1
H33 HEAD COVER BOLT M6 x 60 PSYCG7000EH33
1
H09 IGNITION COIL PSYCG7000EH09 1
H34 FLANGED BOLT M6 x 12 PSYCG7000EF14
1
H10 BOLT M6 x25 PSYCG7000EH10 2
H35 II DA PSYCG7000EH35
1
H11 OIL SEAL Ø52 x Ø35 x 8 PSYCG7000EH11 1
H36 RUBBER BAND PSYCG7000EH36
1
H12 SPEED REGULATING WHEEL PSYCG7000EH12 1
H37 FLANGED BOLT M6 x 12 PSYCG7000EF14
1
H13 FLAT WASHER Ø8.2 x Ø13 PSYCG7000EA42 1
H38 BRACKET PSYCG7000EH38
1
H14 CRANKCASE PSYCG6000EH14 1
H39 FLANGED BOLT M6 x 25 PSYCG7000EH39
2
H15 FLANGED BOLT M12 x 16 PSYCG7000EH15 1
H40 ELECTRIC MAGNET PSYCG7000EH40
1
H16 WASHER Ø 17 PSYCG7000EH16 1
H41 ENGINE HOLE COVER PSYCG7000EH41
3
H17 OIL SENSOR PSYCG7000EH17 1
H42 BEARING 6202 PSYCG7000EH42
2
H18 FLANGED BOLT M6 x 12 PSYCG7000EF14 2
H43 BALANCER SHAFT PSYCG7000EH43
1
H19 CRANK CASE BEARING 6207 PSYCG7000EH19 2
H44 FLANGED BOLT M6 x 12 PSYCG7000EF14
3
H20 LOCATING RING PSYCG7000EH20 2
H45 AIR FLOW GUIDE PSYCG7000EH45
1
H21 CAMSHAFT PSYCG6000EH21 1
H46 CYLINDER HEAD RUBBER WASHER PSYCG7000EH46
1
H22 VALVE LIFTER PSYCG7000EH22 2
H47 WASHER Ø6 x Ø10 PSYCG7000EH47
1
H23K GEAR CASE SEAL KIT (Includes H23 & 27) PSYCG7000EH23K
1
H48 OIL CAP PSYCG7000EH48
1
H23 CRANK CASE GASKET PSYCG7000EH23 1
H49 HEAD COVER WASHER PSYCG7000EH49
1
H24 OIL LEVEL PLUG PSYCG7000EH24 1
