The D70 display uses 1 or 2 sensors to carry out any kind of measurement testing. Basic
measurements (using a sensor) can be carried out, as can measurements of sums and meas-
urements of differences.
The screen can be split to show two displays. The D70 can make direct (static) measurements
or dynamic measurements (min, max, etc.)
Measurements can be made in comparison to a reference level, i.e. a benchmark.
The D70 has a large number of customisable functions, making it suitable for a vast range of
testing applications. The D70 display can be connected to a PC using its RS-232 and USB ports.
A multifunctional pedal can also be connected to the device.
Introduction
D70S
Connections for Syl-
vac-brand or other
compatible capacitive
sensors
D70H
Connections for Heid-
enhain sensors
D70I
Connections for Syl-
vac-brand or other
compatible inductive
sensors
Main technical features
tColour 4.3» touchscreen, 480 x 272 resolution
tStatic or dynamic measurements (min, max, average, etc.)
tAnalogue and digital display
t2 measurement configurations (2 measurements)
tOption to automatically select the configuration or select using the touchscreen
tRelative or absolute display selected using the touchscreen
tDisplay precision (from 2 to 5 decimal places)
tMetric (mm or µm) or imperial (in) units
tRS-232 port for PC communication
tM-Bus port for I/O connection
tUSB port for PC connection and/or power supply
Features
Versions
4
