4
MINMAX
PRESET
TOL INPUT
2
x
1
IN
mm
H
B
B
1. Left measurement jaw
2. Right measurement jaw
3. Measurement button
4. Left moving cursor locking lever
5. Right cursor clamp knob
6. Internal measurement plunger clamp knob
7. Pressure cursor
8. Pressure cursor locking lever
9. Pressure indicator
10. SET button
11. Favourites button
12. Mode button
13. Battery cover
14. Display
15. Internal interchangeables measurement plungers
16. Main beam
17. Proximity cable housing
16
15
17
4 14 5 10 8 7
13 12 11 9
2
15
1
6
3
Pressure indicator
Middle position
Measuring position
(external measurement)
Measuring position
(internal measurement)
