12. Body Cover
12-14
Remove the upper 1 bolt from the tail light.
Remove the rear side 2 bolts.
Remove tail light and winker light coupler.
Remove 1 bolt on the left & right each side of rear
fender.
Remove rear fender and tail light.
Installation
Install according to the reverse procedure of
removal.
Bolt x 2
Bolt
Tail light coupler
Bolt x 1
