Symbol DS6708 - Page 26

To Next Page

To Previous Page

1 - 6 Symbol DS6708 Digital Scanner Product Reference Guide

For convenience, print this page and use the template below for mounting hole locations.

Figure 1-7

Wall Mounting Template

2.98”

Insert mounting

screw

Insert mounting

screw
