DOC06501_Revision F
ATS-6501 Users Guide
13
[altitude] 5.1573999999999998e+01
[latitude] 3.8466278930940000e+01
[longitude] -7.7440865422740004e+01
ATS-6501>settings gps:datum
wgs84
If these settings are correct type save to save the current position on the system to ensure
the system uses the manual positioning mode after a reboot or power cycle.
2.4 ATS-6501 Installation
The ATS-6501 is ready for installation into a standard 19" (48.3 cm) rack using either
slides or shelves and will take up 1U of rack space. The C-300-S Series rack slides from General
Devices or equivalent slides are recommended.
CAUTION: Use the screws provided with the unit to mount the rails to the side of the chassis.
If longer screws are used, you could damage the power supplies or prevent them from being
removed from the chassis.
2.4.1 Power Supplies
The ATS-6501 operates with two power supplies capable of operating on different power
sources. The 4385A (AC Power Supply) and 4386A (DC Power Supply) are available. The
ATS-6501 is capable of operating on one power supply in the event the other fails or its input
source fails. Power Supply #1 is on the left and Power Supply #2 is on the right. See Appendix
A for the specifications on the Power Supplies.
2.4.2 Output Cards
The ATS-6501 has the capability using six output cards in each unit. The cards slots are
identified by number so the operator is capable of determining the slot of the card in the show
command and identifying the cards physical location in the chassis. The view below is from the
rear of the unit from left to right.
Slot 1 Slot 3 Slot 5
Slot 2 Slot 4 Slot 6
Figure 3 Rear Panel Output Card Locations
This ATS-6501 will operate with five different types of output cards. The output cards
can be operated in any of the six slots. The unit will automatically detect and configure the
system based on the cards installed. The cards are also hot swappable. Each output card has four
output connectors with the output number identified as shown below in Figure 2-4. See
Appendix A for the specifications of each output module.
