1. Mount the Mic-D1 microphone on a boom pole
through the mic holder with 3/8" - 5/8" connector.
2. Put the foam windscreen on the Mic-D1
microphone.
3. Connect the Mic-D1 microphone to Camcorder/
Mixer using a XLRM-XLRF cable.
4. Connect the Mic-D1 microphone to Camera
using a 3.5mm-XLRF cable.
Mounting the Shotgun Mic
1. Polar Pattern: Hyper Cardioid
Speci󽗉cations
2. AA Battery/ 48V Phantom Power
SYNCO Mic-D1 runs on 48V phantom power, or is
powered by one AA battery for about 100 hours.
AA battery
48V phantom power
3. Performance Parameter
Model
Element
Polar Pattern
Frequency Response
Signal to Noise Ratio
Sensitivity
Max.Input SPL
Mic-D1
Back Electret Condenser
Hyper-Cardioid
40Hz - 20,000Hz
78dB（1KHz at 1Pa）
-34dB/-32dB±2dB（1dB=1V/Pa at 1kHz）
130dB
